factory price Pin Header

P/N: WPH-8019-2XX-2GXB-XR
Packing: Bag/Tray/Tape Reel
Delivery time: 10~20 Days
RoHS/HF/GP Compliant
Availability:
  • WPH-8019-2XX-2GXB-XR

  • winconn

Product Description

Pin Header Pitch=2.54mm Double Row Vertical SMT Type

P/N: WPH-8019-2XX-2GXB-XR


factory price Pin Header

factory price 2.54mm Pin Header

factory price 2.00mm Pin Header

factory price 1.27mm Pin Header

factory price 1.00mm Pin Header

factory price 0.80mm Pin Header

factory price 1.50mm Pin Header

factory price 3.96mm Pin Header

factory price 5.08mm Pin Header


1. MATERIAL:

HOUSING: THERMOPLASTIC,HIGH TEMP, 30% G/F

UL 94V-0, COLOR:BLACK.

CONTACT: BRASS.


2. FINISH:

CONTACT: AU PLATING OVER NI(50m" MIN.)

3.ELECTRICAL:


CONTACT RESISTANCE: 20mΩ Max.

INSULATION RESISTANCE: 1000MΩ Min.

DIELECTRIC WITHSTANDING VOLTAGE: 500V AC

CURRENT RATING: 3A


4.ENVIRONMENTAL:

OPERATING TEMPERATURE: -25°C TO +85°C


WPH-8003-2XX-2GXB-XR
