Copper Alloy High current 0.031"(0.8mm) Pitch Box Header connector

Box Header Pitch 2.00mm Vertical SMT Type

P/N: WBH-7005-2XX-2GXB-XR

NOTE:

1.MATERIAL:

 HOUSING:HIGH TEMPERATURE THERMOPLASTIC UL94V-0

 CONTACT:COPPER ALLOY.

2.PLATING:

 CONTACT:GOLD PLATED OVER Ni

3.ELECTRICAL:

CONTACT RESISTANCE:20 MILLIOHMS

INSULATION RESISTANCE:1000 MEGOHMS

DIELECTRIC WITHSTANDING VOLTAGE:100 AC

CURRENT RATING:2.0A

VOLTAGE RATING:125V AC/DC

4.ENVIRONMENTAL:

OPERATING TEMPERATURE:-45℃ TO+105℃
